Product Description
FEATURES
-
Rear Mounted DIP Switch Allows Mute Receive for Inputs 2 and 3
-
Contact Closure Mute Terminals
-
Variable Mute Sensitivity Control for Input 1
-
Preamp In for External Processors
-
Line Output
-
Remote Input Select (RIS)
-
Remote Level Control
-
Input Assignable Zone 2 Output
-
Two Unbalanced, Summing Line Level Inputs
-
Two Balanced Mic/Line/Tel Inputs w/ Phantom Power
-
Automated Diagnostic System Test (Push Here Diagnostic®)
-
100W into 25V/70.7V and 4Ω Loads
Optional Rack Mount Kit Available, Model AARMK2-5
SPECIFICATIONS
| Frequency Response | 50Hz - 15kHz |
| Connector Type | 4 Position Phoenix 3.5mm Pitch |
| Power Output | Max. Average Power @ 50Hz-15kHz with .5% THD, 4Ω 100W RMS |
| Height | 3.66" (93mm) |
| Width | 8.27" (210mm) |
| Depth | 10.87" (276mm) |
| Weight | 13lb |
| Shipping Weight | 15.2lb |
| Voltage Compatibility | 110V - 120V |
| Warranty Period | 36 months from date of purchase |
